Precision Flanged Drive Pin CNC Machined Zinc Plated Carbon Steel Tight Tolerance Custom Drawing Bulk For Sewing Machine Motor
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | ISO9001 |
| Model Number | TF-001 |
| Minimum Order Quantity | 1 |
| Price | 0.01-9.99 |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | T/T |
| Supply Ability | 10000000pieces/per month |
Product Details
| Product Type | Flanged Drive Pin / Locating Pin / Transmission Pin / Connection Pin | Main Material | Carbon Steel / Alloy Steel / Bearing Steel / Stainless Steel |
|---|---|---|---|
| Surface Finish | Zinc Plated / Eco-Friendly Zinc Plated / Chrome Plated / Phosphating / Black Oxide | Process Type | CNC Turning / Flange Forming / End Grinding / Chamfering / Drilling / Tapping |
| Diameter Range | 4mm - 30mm / 30mm - 50mm | Length Range | 15mm - 80mm / 80mm - 150mm |
| Certification | ISO 9001 / RoHS / REACH | Drawing Format | PDF / STEP / DWG/DXF / IGES |
| Highlight | Precision flanged drive pin CNC machined,Zinc plated carbon steel sewing machine motor pin,Custom drawing bulk drive pin with warranty |
||
Product Description
Precision Flanged Drive Pin for Sewing Machine Motors
Tingfeng Hardware specializes in precision flanged drive pins manufactured with CNC machining processes using zinc plated carbon steel material. These components are specifically designed for sewing machine motors and industrial sewing equipment, featuring strict dimensional tolerance control for precise fit with motor output shafts and linkage mechanisms.
Product Overview
Flanged drive pins serve as critical connecting components between sewing machine motors and transmission mechanisms. Manufactured through precision CNC turning and end grinding processes, our products ensure excellent coaxiality and perpendicularity between flange face and pin shaft. Tight tolerance control guarantees optimal interference or clearance fit with mating holes, while zinc plated carbon steel provides both strength and corrosion resistance.
Features & Advantages
| Feature | Advantage |
|---|---|
| Tight tolerance control | Diameter tolerance ±0.01-0.02mm ensures precise fit and smooth transmission |
| Precision ground flange face | Flange perpendicularity ≤0.015mm ensures accurate axial positioning, reducing vibration |
| Uniform and dense zinc plating | Salt spray test 48 hours meets corrosion protection needs of industrial sewing environments |
| High-strength carbon steel | Tensile strength ≥600MPa meets strength requirements of high-frequency reciprocating motion |
| Customized bulk production | Custom per drawing, stable bulk supply ensures uninterrupted production lines |
Technical Specifications
| Specification Item | Detail / Range | Tolerance / Standard |
|---|---|---|
| Material | Carbon Steel / Alloy Steel | Tensile ≥600MPa |
| Surface Finish | Zinc Plated / Nickel Plated / Black Oxide | Salt spray ≥48 hours |
| Pin Diameter Tolerance | ±0.01mm / ±0.02mm | Per drawing |
| Flange Thickness Tolerance | ±0.05mm | Per drawing |
| Flange Perpendicularity | ≤ 0.015mm | Face runout guaranteed |
| Coaxiality | ≤ 0.02mm | Geometric tolerance |
| Surface Roughness | Ra 0.4μm – 1.6μm | Process dependent |
| Hardness | HRC 25 – HRC 50 | Material and heat treatment dependent |
Applications
Sewing Machine Motor Applications:
- Industrial sewing machine motor drive pins
- Home sewing machine transmission pins
- Embroidery machine actuator connecting pins
- Overlock machine transmission pins
- Garment production equipment linkage pins
- Textile machinery locating pins
Other Applications:
Light industry transmission mechanisms, packaging equipment connecting components
Frequently Asked Questions
Can you handle complex custom designs and provide design optimization suggestions?
Absolutely. This is our core expertise. We provide free DFM analysis within 3-5 days, often helping clients achieve 15-30% cost reduction through design for manufacturability.
How do you ensure quality consistency and handle defect issues?
We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows 99.99% qualification rate.
What are your lead times and how do you handle urgent orders?
Standard lead times: 3-7 days for prototypes, 7-15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Will I get timely responses and professional support throughout the project?
Yes. You get a 1v1 exclusive consultant with 1-hour initial response commitment and 24-hour technical support.
Can you provide material certifications and environmental compliance reports?
Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
How do you protect my designs and intellectual property?
We start with mutual NDA and implement strict mold ownership protection and confidential data security measures.
What are your payment terms and MOQ requirements?
We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
