Customize Surface Mount Nuts Rapid Prototyping For Automated PCB Assembly
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | lSO9001 |
| Model Number | TF-002 |
| Minimum Order Quantity | 1 |
| Price | 0.08-0.12USD |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | T/T |
| Supply Ability | 10000000pieces/per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Type | Surface Mount Nut (SMT) | Mounting Process | Reflow Soldering |
|---|---|---|---|
| Body Material | Stainless Steel 304/316, Low Carbon Steel | Surface Finish | Tin Plating, Nickel Plating, Silver Plating |
| Solder Compatibility | Suitable For Lead-Free (Pb-Free) Reflow Process | Typical Application | PCB Board Reinforcement, Modular Connection |
| Precision Grade | Precision (±0.05mm) | Packaging Form | Tape And Reel |
| Highlight | Rapid Prototyping Surface mount nuts,PCB Assembly Surface mount nuts,Customize non standard Nuts |
||
Product Description
Reflow Solderable SMT Nuts for Automated PCB Assembly | Custom Thread Sizes & Rapid Prototyping
1.SMT NutsQuick Detail
Our SMT Nuts are designed for modern electronic assembly, enabling automated, high-precision placement of nuts. These nuts are fixed via reflow soldering alongside other SMD components during PCB assembly, providing a solid threaded base for subsequent stacked installation or external connections. This process eliminates the steps of traditional stud welding or through-hole installation, significantly improving assembly efficiency, consistency, and saving board space.
2.SMT NutsProduct Description
In electronic designs pursuing thin, light, compact, and high reliability, the mounting method of every component is critical. Our SMT Nuts, as an innovative interconnection solution, seamlessly integrate sturdy metal threaded interfaces into the SMT production flow. They are precision-designed with a flat soldering surface at the bottom to ensure good solder wetting and adhesion strength, while their structure effectively withstands the thermal stress of reflow soldering. This provides your product with repeatable, reliable mechanical connection points, ideal for interface locations requiring frequent mating/unmating or bearing certain stress.
3.SMT NutsProduct Features & Advantage
|
Feature |
Advantage to You |
|
Compatible with Full Auto SMT Lines |
Standard tape and reel packaging is compatible with pick-and-place machines, enabling high-speed, accurate automatic placement, greatly improving PCB assembly efficiency and reducing labor costs and errors. |
|
Excellent Solder Reliability & Consistency |
Optimized bottom plating and structure design ensure the formation of uniform, robust solder joints during reflow, providing stable mechanical strength and electrical grounding (if required). |
|
Provides Reliable Threaded Base for PCB |
Creates strong metal threaded holes on thin PCBs, effectively preventing thread stripping, and withstands multiple tightenings and removals, extending connection point lifespan. |
|
Saves Valuable PCB Space & Layers |
No need for through-holes, saving routing space, allowing threaded connections on the solder side, simplifying stacked design and housing mounting. |
|
Stringent Quality & Traceability Control |
From raw material to finished product, quality control follows strict electronics industry standards, ensuring batch-to-batch stability in dimensional accuracy, plating thickness, and solderability. |
4.SMT Nuts.Product Specification
|
Specification Item |
Detail / Capability |
Notes / Description |
|
Common Thread Sizes |
M2, M2.5, M3, M4, #2-56, #4-40, #6-32 |
Supports Metric and Imperial |
|
Body Height (Standoff) |
Various standard height options, e.g., 1.0mm, 1.5mm, 2.0mm |
Customizable per requirement |
|
Solder Side Plating |
Matte Sn, Bright Sn, Ni (underlayer) |
Plating thickness complies with IPC standards |
|
Terminal/Pad Design |
Square pad, Round pad, Pad with locating peg |
Optimized for solder strength & self-alignment |
|
Current Carrying Capacity (if applicable) |
Meets general grounding or signal connection needs |
Specific values depend on design & material |
|
Reflow Temperature Resistance |
Withstands lead-free reflow profiles up to 260°C peak |
|
|
Packaging Details |
EIA-481 compliant tape and reel, typically 13-inch reel diameter |
Adjustable per pick-and-place machine requirement |
5.SMT NutsProduct Application
Our SMT Nuts are the ideal choice for achieving high-density, high-reliability electronic connections, widely used in:
Communication & Networking Equipment: Used for shielding can fixation in 5G base station modules, PCB inter-board support and connection in routers/switches, providing reliable grounding and mechanical fixation.
Automotive Electronics: Applied in engine control units (ECUs), infotainment systems, housing-to-PCB grounding connections for vehicle sensors, meeting vibration resistance and high-reliability requirements.
Industrial Control & Automation: Serve as mounting standoffs for PLC modules and I/O modules, enabling quick locking of modules to backplanes or chassis, facilitating maintenance and upgrades.
Consumer Electronics & Computing: Used for fixing Solid State Drives (SSDs), connecting internal brackets in laptops, and providing auxiliary support points for high-end graphics cards, saving internal space.
sked Questions (FAQ)
Q: Can you handle complex custom designs and provide design optimization suggestions?
A: Absolutely. This is our core expertise. We provide free DFM analysis within 3-5 days, often helping clients achieve 15-30% cost reduction through design for manufacturability.
Q: How do you ensure quality consistency and handle defect issues?
A: We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows 99.99% qualification rate.
Q: What are your lead times and how do you handle urgent orders?
A: Standard lead times: 3-7 days for prototypes, 7-15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Q: Will I get timely responses and professional support throughout the project?
A: Yes. You get a 1v1 exclusive consultant with 1-hour initial response commitment and 24-hour technical support.
Q: Can you provide material certifications and environmental compliance reports?
A: Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
Q: How do you protect my designs and intellectual property?
A: We start with mutual NDA and implement strict mold ownership protection and confidential data security measures.
Q: What are your payment terms and MOQ requirements?
A: We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
