Customizable Cnc Turning Components High Precision For Engineered Components
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | ISO9001 |
| Model Number | TF-002 |
| Minimum Order Quantity | 1 |
| Price | 0.10-0.60USD |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | T/T |
| Supply Ability | 10000000pieces/per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Type | Precision Machined Parts / CNC Turned Parts / CNC Milled Parts / Turn-Mill Parts / Rapid Prototypes | Machining Precision | Standard (±0.05mm) / Precision (±0.01mm) / High-Precision (±0.005mm) |
|---|---|---|---|
| Process | 5-Axis Milling / 6-Axis Milling / 7-Axis Simultaneous / CNC Turning /Turn-Mill Compound / Swiss-Type Machining | Surface Roughness | Ra 3.2μm / Ra 1.6μm / Ra 0.8μm / Ra 0.4μm (Mirror) |
| Certification | ISO 9001 / IATF 16949 / ISO 13485 / AS9100 / ROHS | File Format | STEP / IGES / X_T / DWG / PDF / 3D Print File |
| Highlight | High Precision cnc turning components,Customizable cnc turning components,Customizable CNC Turning Service |
||
Product Description
omplex Multi-Axis CNC Turning Service for Precision Engineered Components
1.CNC Turned Parts Quick Detail
Tingfeng Hardware specializes in the efficient and high-precision manufacturing of CNC turned parts, particularly small, precision rotary components. We utilize Japanese Citizen and Tsugami series sliding headstock lathes (Swiss-type lathes), excelling at completing multiple processes such as turning, milling, drilling, and tapping in a single setup. Whether it's precision valve cores for automotive fuel systems or miniature copper pins for electronic connectors, we can achieve exceptional dimensional consistency and superior surface quality in high-volume production, providing you with cost-effective turning solutions.
2.CNC Turned Parts Product Description
Advanced CNC machining represents the pinnacle of modern precision turning, especially suitable for small-diameter parts with high aspect ratios and complex structures. Our equipment integrates a sub-spindle, back-machining power head, and Y-axis, enabling complex operations such as eccentric drilling, side milling, and back turning to be completed in a single setup, significantly improving accuracy and efficiency. We focus on transforming your turning requirements into a stable, fast, and low-waste production flow, ensuring consistent quality standards from the first piece to millions of pieces through optimized tool management, automatic feeding systems, and real-time monitoring.
3. CNC Turned Parts Product Features & Advantage
|
Feature |
Advantage to You |
|
Swiss-Type Superior Efficiency for Small & Micro Parts |
Designed specifically for parts with diameters Φ1mm-Φ32mm, offering exceptional one-shot machining capability. Ideal for complex small parts with eccentric holes, cross-holes, or flat surfaces, eliminating multiple setups, ensuring concentricity, and greatly improving efficiency. |
|
Strong Batch Production Capability & Cost Advantage |
Achieves low-cost, high-speed mass manufacturing through automatic feeding, programmed cycle times, and efficient tooling solutions, significantly reducing your per-part cost. The preferred choice for mass production of standard parts and connectors. |
|
Complex Turn-Mill & Secondary Operation Integration |
Integrates power tool operations like milling slots, flats, drilling side holes, and tapping angled threads on the basis of precision turning, delivering finished functional parts, reducing subsequent processing steps and supply chain management costs. |
|
Stringent Diameter, Thread & Concentricity Control |
Precisely controls diameters, steps of shaft parts, and various metric/imperial/UN threads. Equipped with in-process inspection and thread gauges for real-time verification, ensuring interchangeability and assembly reliability. |
4.CNC Turned Parts Product Specification
|
Specification Item |
Detail / Range |
Standard / Notes |
|
Turning Diameter Range |
Φ0.5mm — Φ150 mm |
Machine dependent |
|
Swiss-Type Specialization |
Φ1mm — Φ32mm (Bar Stock) |
One-setup |
|
Max. Turning Length |
Swiss-Type: up to 300mm; Lathe: longer |
Process dependent |
|
Thread Machining Capability |
M0.8 to M60 Metric, UN, NPT, Whitworth, etc. |
Comprehensive tooling available |
|
Concentricity/Runout Control |
≤ 0.005 mm (One Setup) |
Standard achievable capability |
|
Material Adaptability |
Wide range, including free-cutting steel, brass, stainless steel, aluminum, etc. |
Material advice provided |
5.CNC Turned Parts Product Application
Our CNC turned parts are fundamental and critical connecting components in numerous industries:
Automotive Industry and Fuel Systems: Fuel injector components, sensor housings, gearbox shafts, various bolts and bushings, requiring high wear resistance, corrosion resistance, and dimensional consistency.
Medical and Dental Instruments: Surgical instrument handles, implant prototypes, dental implant components, miniature orthopedic screws, requiring excellent biocompatible surfaces and precision threads.
Electronics and Communication Equipment: Mobile phone vibration motor shafts, fiber optic connector ferrules, RF connectors, heat sink copper posts, emphasizing high conductivity (electrical/thermal) and precise fit.
General Industrial and Fluid Control: Pneumatic fittings, valve spindles, metering pump rotors, various standard and non-standard fasteners, emphasizing sealing performance, durability, and reliability.
6.Frequently Asked Questions (FAQ)
Q: Can you handle complex custom designs and provide design optimization suggestions?
A: Absolutely. This is our core expertise. We provide free DFM analysis within 3-5 days, often helping clients achieve 15-30% cost reduction through design for manufacturability.
Q: How do you ensure quality consistency and handle defect issues?
A: We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows 99.99% qualification rate.
Q: What are your lead times and how do you handle urgent orders?
A: Standard lead times: 3-7 days for prototypes, 7-15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Q: Will I get timely responses and professional support throughout the project?
A: Yes. You get a 1v1 exclusive consultant with 1-hour initial response commitment and 24-hour technical support.
Q: Can you provide material certifications and environmental compliance reports?
A: Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
Q: How do you protect my designs and intellectual property?
A: We start with mutual NDA and implement strict mold ownership protection and confidential data security measures.
Q: What are your payment terms and MOQ requirements?
A: We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
