Non Standard Stainless Steel Torsion Spring For Medical Devices Automotive Actuators
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | lSO9001 |
| Model Number | TF-003 |
| Minimum Order Quantity | 1 |
| Price | 0.01-0.50USD |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | ,T/T |
| Supply Ability | 10000000pieces/per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Component Name | Non-Standard Extension Spring | Base Material | Carbon Steel Wire (Pre-plating) / Austenitic Stainless Steel / Martensitic Stainless Steel (Hardenable) / Special Wire |
|---|---|---|---|
| Machining Precision Grade | Commercial Grade / Precision Grade / Instrument Grade | Load Characteristic | Constant Rate / With Initial Tension / Progressive Rate (Conical) |
| End Treatment Method | Mechanically Wound Loop / Added Stud / Welded Ring / Crimped Ring | Corrosion Protection Grade | Basic / Standard / Heavy-Duty / Food Contact Grade |
| Target Market | Aftermarket / OEM Support / MRO Market / Export Specific | Service Package | Manufacturing Only / Including Design / Including Test Report / Including Logistics |
| Highlight | Non Standard stainless steel torsion spring,Medical Devices stainless steel torsion spring,Automotive Actuators Precision Extension Springs |
||
Product Description
Precision Tension Spring Solutions | From Simulation & DFM to High-Capacity Delivery
1.Tension Spring Quick Detail
We specialize in solving the challenges of complex tension spring applications. Leveraging our precise control over materials with wire diameters ranging from 0.1-12mm and a deep understanding of hook and loop mechanics, we provide high-performance customized products for clients in medical devices, automotive actuators, and high-end electronics. Our factory operates under the IATF 16949 automotive quality management system. Combined with our rapid response capability with over 200 molds and a daily production capacity of 500,000 pieces, we not only guarantee superior product quality but also ensure timely and stable supply, making us a strategic supplier you can trust.
2.Tension Spring Product Description
At Tingfeng Hardware, we treat every extension spring project as a unique engineering proposition. We focus on the spring's role within the entire force chain: it is both a flexible connector and a precise force generator. Our value lies in using advanced simulation software and empirical formulas to predict the spring's load-deflection curve, stress distribution, and potential failure modes at the design stage. We work closely with you to make optimal decisions on material selection (balancing cost and performance), end configuration (ensuring installation convenience and strength), and manufacturing processes (e.g., stress relief to resist relaxation), ultimately delivering a fully validated, ready-for-assembly critical component.
3.Tension Spring Product Features & Advantage
|
Feature |
Advantage to You |
|
Simulation-Based Design Verification |
Evaluates spring performance through computer simulation before manufacturing, identifying design flaws early, saving time and cost of physical trial and error. |
|
Comprehensive Failure Analysis & Prevention |
Possesses the capability to analyze common failures (e.g., hook breakage, tension relaxation) and implants preventive measures in the process, enhancing product reliability. |
|
Scalable Capacity & Supply Chain |
Smooth transition from prototype to volume production, along with a raw material system with safety stock, ensures no worries for your project growth. |
|
Comprehensive Product Documentation |
Can provide a complete document package including critical dimension reports, load test data, and material certificates with shipment, facilitating your quality traceability and warehousing. |
4. Tension Spring Product Specification
|
Category |
Parameter |
Typical Value / Range |
|
A. Design Input Parameters |
|
|
|
|
Mounting Length & Corresponding Load |
Customer Specified |
|
|
Max. Operating Extended Length |
Customer Specified |
|
|
Operating Environment (Temp, Medium) |
Customer Specified |
|
B. Key Output Parameters |
|
|
|
|
Recommended Wire Diameter & Material |
Calculated and Suggested per Input |
|
|
Theoretical Initial Tension |
Calculated per Design |
|
|
Theoretical Spring Rate |
Calculated per Design |
|
|
Safety Factor |
Calculated and Reported based on Max. Extension |
|
C. Manufacturing Capability Parameters |
|
|
|
|
Min/Max Manufacturable OD |
≈1.0mm / ≈100mm |
|
|
Loop Machining Accuracy (Position) |
±0.5mm (Standard) |
5.Tension Spring Product Application
Providing tensile solutions for demanding applications:
Dynamic high-cycle applications: Copier paper feed mechanisms, textile machinery heald springs, and high-speed labeling machine tension springs, requiring extremely high cycle life and extremely low plastic deformation.
Precision force control applications:Laboratory instrument sample holders, semiconductor equipment conveyor arm balance springs, and optical adjustment mechanisms, demanding stringent requirements for force linearity and repeatability.
Harsh environment applications:Tension springs in agricultural machinery, marine equipment components, and chemical process valve springs, requiring spring materials or coatings with extremely high environmental resistance.
Space-constrained applications: Miniature tension springs in consumer electronics (such as wearable devices) and compact valve actuators, requiring specific tension and stroke within extremely small spaces.
6. Frequently Asked Questions (FAQ)
Q: Can you handle complex custom designs and provide design optimization suggestions?
A: Absolutely. This is our core expertise. We provide free DFM analysis within 3-5 days, often helping clients achieve 15-30% cost reduction through design for manufacturability.
Q: How do you ensure quality consistency and handle defect issues?
A: We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows 99.99% qualification rate.
Q: What are your lead times and how do you handle urgent orders?
A: Standard lead times: 3-7 days for prototypes, 7-15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Q: Will I get timely responses and professional support throughout the project?
A: Yes. You get a 1v1 exclusive consultant with 1-hour initial response commitment and 24-hour technical support.
Q: Can you provide material certifications and environmental compliance reports?
A: Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
Q: How do you protect my designs and intellectual property?
A: We start with mutual NDA and implement strict mold ownership protection and confidential data security measures.
Q: What are your payment terms and MOQ requirements?
A: We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
