Precision Non-Standard Stamped Spring Contacts for Encoder & Sensor PCBs – 1M+ Cycles
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | lSO9001 |
| Model Number | TF-001 |
| Minimum Order Quantity | 1 |
| Price | 0.07-0.23USD |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | T/T |
| Supply Ability | 10000000pieces/per month |
Product Details
| Product Type | Non-Standard Encoder Spring Contacts / Custom Sensor PCB Terminals / High-Life Stamped Contacts | Main Material | Beryllium Copper C17200 / Phosphor Bronze / Gold-Plated Steel |
|---|---|---|---|
| Material Thickness | 0.05-0.1mm / 0.1-0.15mm / 0.15-0.2mm | Process Type | Precision Progressive Die Stamping / Bending Forming / Stress Relief Heat Treatment / Non-Standard Customization |
| Surface Finish | Gold Plating / Silver Plating / Nickel Plating | Contact | ≤5mΩ / ≤10mΩ |
| Tolerance Grade | High-Precision (±0.01mm) / Ultra-High-Precision (±0.005mm) | Cycle Life | ≥1,000,000 Cycles / ≥3,000,000 Cycles |
| Highlight | stamped spring contacts for encoder PCBs,precision non-standard spring contacts,1M+ cycle stamped spring contacts |
||
Product Description
Tingfeng Hardware provides non-standard stamped spring contacts for encoder and sensor PCBs, manufactured from BeCu C17200 with force decay under 10% after 1 million rotation or sliding cycles, contact resistance ≤5mΩ, and tolerance of ±0.005mm. With 16 years of precision manufacturing experience, we understand that encoders and sensors demand long-term signal stability and maintenance-free operation — our spring contact solution directly serves this requirement and provides customized contact geometry design for different PCB layouts.
Product Overview
Spring contacts on encoder and sensor PCBs must maintain contact resistance without drift over millions or even tens of millions of movements, directly determining signal accuracy and system stability. Our BeCu C17200 contacts achieve precise geometry through precision stamping, stress relief heat treatment eliminates internal stress, and gold plating controls contact resistance below 5mΩ. For different PCB layouts and motion types (rotary or sliding), we provide non-standard customized spring geometry design. On the commercial side, clients increasingly focus on total cost of ownership — the value of a million-cycle contact lies in reducing downtime maintenance, extending calibration intervals, and ensuring continuous equipment operation.
Precision metal stamping parts manufacturing process
Features & Advantages
| Feature | Advantage to You |
|---|---|
| BeCu C17200 million-cycle life | Force decay <10%, reducing encoder/sensor maintenance downtime |
| Non-standard custom spring geometry | Adapts to different PCB layouts and rotary/sliding motion types |
| ±0.005mm ultra-high precision | Adapts to high-resolution discs and precision sensing layouts, ensuring signal accuracy |
| Stress relief heat treatment | Avoids signal drift from stress relaxation over long-term cycling |
| DFM engineering collaboration | Optimizes spring geometry and material matching from design stage, shortening development cycles |
Precision metal stamping parts quality inspection
Product Specifications
| Specification Item | Detail / Range | Tolerance / Standard |
|---|---|---|
| Material Type | Beryllium Copper C17200 / Phosphor Bronze | Per drawing |
| Material Thickness | 0.05 mm – 0.2 mm | ±0.003mm |
| Contact Resistance | ≤ 5 mΩ (Gold) | Measured |
| Contact Force | 0.1 N – 0.8 N | ±10% |
| Dimensional Accuracy | ±0.005mm – ±0.01mm | Per drawing |
| Cycle Life | ≥ 1,000,000 | Force decay <10% |
| Surface Finish | Gold / Silver Plating | Thickness controlled |
| Operating Temperature | -20°C – +100°C | Industrial Grade |
Product Applications
Encoders
Rotary encoder spring contacts, potentiometer sliding contact tabs, grating read head springs.
Sensor PCBs
Pressure sensor signal terminals, position sensor contact springs, torque sensor elastic contacts.
Precision Feedback
Servo system feedback terminals, closed-loop control sensor contacts.
Industrial Electronics
Precision potentiometer contact tabs, sliding switch springs.
Frequently Asked Questions
Can you handle complex custom designs and provide design optimization suggestions?
Absolutely. This is our core expertise. We provide free DFM analysis within 3–5 days, often helping clients achieve 15–30% cost reduction through design for manufacturability.
How do you ensure quality consistency and handle defect issues?
We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows a 99.99% qualification rate.
What are your lead times and how do you handle urgent orders?
Standard lead times: 3–7 days for prototypes, 7–15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Will I get timely responses and professional support throughout the project?
Yes. You get a 1v1 exclusive consultant with a 1-hour initial response commitment and 24-hour technical support.
Can you provide material certifications and environmental compliance reports?
Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
How do you protect my designs and intellectual property?
We start with a mutual NDA and implement strict mold ownership protection and confidential data security measures.
What are your payment terms and MOQ requirements?
We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
