Stamped Battery Interconnect Contacts for Medical Devices & Portable Defibrillators – Stainless Steel
| Place of Origin | Shenzhen, China |
|---|---|
| Brand Name | TF |
| Certification | lSO9001 |
| Model Number | TF-001 |
| Minimum Order Quantity | 1 |
| Price | 0.07-0.23USD |
| Packaging Details | Carton packaging 18*15*12cm (packaging can be customized according to customer product requirements) |
| Delivery Time | 3days/Start |
| Payment Terms | T/T |
| Supply Ability | 10000000pieces/per month |
Product Details
| Product Type | Battery Interconnect Contacts / Medical Device Battery Tabs / Defibrillator Power Terminals | Main Material | Stainless Steel 304 / Stainless Steel 316L / Nickel-Plated Steel |
|---|---|---|---|
| Material Thickness | 0.12-0.2mm / 0.2-0.3mm / 0.3-0.4mm | Process Type | Progressive Die Stamping / Bending Forming / Embossing / Trimming |
| Surface Finish | Nickel Plating / Gold Plating / Passivation | Contact Resistance | ≤10mΩ / ≤20mΩ |
| Operating Temperature | -20°C To +105°C | Compatible Devices | Portable Defibrillators / Emergency Monitors / Mobile Medical Equipment |
| Highlight | stamped battery interconnect contacts,medical device stainless steel contacts,portable defibrillator battery contacts |
||
Product Description
Stamped Battery Interconnect Contacts for Medical Devices & Portable Defibrillators – Stainless Steel
Tingfeng Hardware provides stamped battery interconnect contacts specifically for medical devices and portable defibrillators, manufactured from stainless steel and nickel-plated steel through precision stamping processes. The contacts are used for high-reliability battery connections in emergency medical equipment, ensuring stable power supply in critical situations. With 16 years of precision manufacturing experience, products meet the stringent requirements of medical devices for reliability and long-term stability.
Product Overview
Portable defibrillators and emergency medical devices have extremely high requirements for battery connection reliability—in emergency treatment scenarios, power interruption can directly endanger patient lives. Our battery interconnect contacts use stainless steel or nickel-plated steel, achieving stable contact force and low contact resistance (≤10mΩ) through precision stamping and bending forming. Nickel or gold plating ensures oxidation resistance and long-term reliability. The contact design accommodates vibration and shock during device transport and use, maintaining stable battery-to-PCB connection. Each contact undergoes 100% dimensional inspection and contact resistance testing, suitable for AED automated external defibrillators, emergency monitors, mobile medical equipment, and other life support systems.
Features & Advantages
| Feature | Advantage to You |
|---|---|
| High-reliability battery connection | Contact resistance ≤10mΩ, ensuring stable emergency power supply for life-saving equipment |
| Anti-vibration design | Optimized spring structure maintains reliable contact during device transport and use |
| Low contact resistance | Gold/nickel plating provides long-term oxidation resistance, ensuring stable signal and power transmission |
| Corrosion-resistant materials | 316L stainless steel and nickel-plated steel, compatible with medical device sterilization and storage environments |
| Full batch traceability | Each batch traceable, with complete inspection reports and material certificates provided |
Product Specifications
| Specification Item | Detail / Range | Tolerance / Standard |
|---|---|---|
| Material Type | Stainless Steel 304 / Stainless Steel 316L / Nickel-Plated Steel | Medical Grade |
| Material Thickness | 0.12 mm – 0.4 mm | ±0.005mm |
| Contact Resistance | ≤ 10 mΩ | Measured |
| Surface Finish | Nickel / Gold / Passivation | Thickness controlled |
| Operating Temperature | -20°C – +105°C | Medical Grade |
| Salt Spray Test | ≥ 72 hours | No corrosion |
| Packaging | Anti-static Packaging / Tape & Reel | As required |
| Compatible Equipment | AED Defibrillators / Emergency Monitors / Mobile Medical Equipment | Per customer requirement |
Product Applications
- Emergency Defibrillation Equipment: AED automated external defibrillator battery interconnect contacts, emergency kit power terminals, CPR device battery connector tabs
- Mobile Monitoring Equipment: Portable ECG monitor battery contacts, emergency transport monitor power terminals, wireless vital signs monitor connector tabs
- Medical Mobile Power: Medical device backup power contacts, emergency cart power connection terminals, mobile medical workstation battery contact tabs
- Pre-Hospital Emergency Care: Emergency kit device battery contacts, field emergency monitor power terminals, defibrillator monitor battery connection springs
Frequently Asked Questions
Can you handle complex custom designs and provide design optimization suggestions?
Absolutely. This is our core expertise. We provide free DFM analysis within 3-5 days, often helping clients achieve 15-30% cost reduction through design for manufacturability.
How do you ensure quality consistency and handle defect issues?
We implement a rigorous 4-stage QC system with 100% full inspection. Our track record shows 99.99% qualification rate.
What are your lead times and how do you handle urgent orders?
Standard lead times: 3-7 days for prototypes, 7-15 days for mass production. We offer VIP prioritization cutting lead times by up to 30%.
Will I get timely responses and professional support throughout the project?
Yes. You get a 1v1 exclusive consultant with 1-hour initial response commitment and 24-hour technical support.
Can you provide material certifications and environmental compliance reports?
Yes. We provide material certifications and environmental test reports (RoHS, REACH compliant) upon request.
How do you protect my designs and intellectual property?
We start with mutual NDA and implement strict mold ownership protection and confidential data security measures.
What are your payment terms and MOQ requirements?
We offer flexible payment terms (T/T, L/C at sight) and MOQ from 1 piece for prototyping.
